Single-Sensor Tracking Module - PUDD075CW
Ultra-Light Single-Sensor AI Tracking Module
The PUDD075CW is a single-sensor tracking module built around a 1.75mm short-focus visible camera. It recognises, locks and tracks targets on its own, weighs 10g, and measures 25 x 19 x 20 mm, so it drops into micro airframes and small gimbal payloads.
Autonomous AI Tracking
The module recognises, locks and tracks a chosen target without operator input.
10g Ultra-Light Body
At 10g the module is among the lightest tracking units flying today.
1.75mm Wide Field Lens
A 1.75mm short-focus lens gives a wide field for close work.
Simple Payload Integration
Low power draw and a standard interface fit most micro drones and gimbals.
Applications
Technical Specifications
- Operating / Storage Temperature
- -20℃ ~ +55℃ / -45℃ ~ +60℃
- Power Supply
- DC 10.8–26.4 V @ 3 A, steady state ≤3 W
- Control Interface
- TTL serial, network
- Visible Sensor
- 1/4" CMOS
- Focal Length
- 1.75 mm
- Photo Resolution
- 1280 × 720
- Video Resolution
- 1280 × 720 @ 100fps
- AI Functions
- Autonomous recognition, locking, tracking
- Camera Module Weight
- 10 g ± 2 g
- Video Output
- Network, analog video
- AI Module Weight
- 42 g ± 2 g
- Dimensions
- 25 x 19 x 20 mm
- Recognition Range
- Over 80 m for an adult target with daytime visibility of at least 8 km
- Recognition Targets
- Person, vehicle
- Field of View
- 113.1° (H) × 63.6° (V) (±5%)
- Target Geolocation
- CEP 10 m
